Description
Intel Core i7 1370P / 1.9 GHz, Win 11 Pro, RTX A500, 32 GB RAM, 1 TB SSD NVMe, Class 35, 15.6" IPS 1920 x 1080 (Full HD), 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth, gray, BTP, with 3 years of basic in place
Weights and Measures
1. Height (Rear): 22.80 mm (0.90 in) Height (Front): 20.80 mm (0.82 in) 2. Width: 357.80 mm (14.09 in) 3. Depth: 233.3 mm (9.19 in)
Takeoff weight (minimum): 1,613 kg (3.56 lb)
Intel® _
Ultrabook, Celeron, Celeron Inside, Core Inside, Intel, Intel Logo, Intel Atom, Intel Atom Inside, Intel Core, Intel Inside, Intel Inside Logo, Intel vPro, Itanium, Itanium Inside, Pentium, Pentium Inside, vPro Inside, Xeon, Xeon Phi, Xeon Inside and Intel Optane are trademarks of Intel Corporation or its subsidiaries in the US and/or other countries.
Generally
Producer
Dell
Product number
3156585
Model
0D10H
To the producer's website
www.dell.com/
Product description
Dell Precision 3580 - 15.6" - Core i7 1370P - 32 GB RAM - 1 TB SSD
Type of product
Mobile workstation
Operating system
Win 11 Pro
Processor
Intel Core i7 (13th Gen) 1370P / 1.9 GHz (5.2 GHz) / 24 MB Cache
Memory
32 GB DDR5 (2 x 16 GB)
Storage
1 TB SSD - NVMe, Class 35
Display
15.6" 1920 x 1080 / Full HD @ 60 Hz - 141 ppi
Graphics
NVIDIA RTX A500
Video memory
4 GB GDDR6 SDRAM
Input device
Keyboard, touchpad
Backlight, keyboard
Yes
Numeric keyboard
Yes
Built-in webcam
Yes
Network functions
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3, Gigabit Ethernet
Battery
3-cell
Characteristics
Accelerometer, ambient light sensor
Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip, smart card reader
Color
Gray
Dimensions (WxDxH)
35.78 cm x 23.33 cm x 2.28 cm
Weight
1,613 kg
Type of pricing
Build To Plan (BTP)
Combined services
3 years of basic on site
Specifications
Generally
Type of product
Mobile workstation
Operating system
Windows 11 Pro
Processor / Chipset
CPU
Intel Core i7 (13th Gen) 1370P / 1.9 GHz
Max. turbo speed
5.2 GHz
Number of cores
14-core
Cache
L3 - 24MB
Functions
Intel Smart Cache
Memory
FRAME
32 GB (2 x 16 GB)
Max. Supported RAM
64 GB
Technique
DDR5 SDRAM
Speed
4800 MHz
Nominal speed
4800 MHz
Form factor
SO DIMM 262-pin
Number of card slots
2
Empty card slots
0
Storage
Main bearing
1 TB SSD M.2 2230 PCIe 4.0 x4 - NVM Express (NVMe), Class 35
Display
Type
15.6" - IPS
Resolution
1920 x 1080 (Full HD)
Vert. Sync. frequency at max.
60 Hz
Widescreen
Yes
Pixel density (ppi)
141
Image brightness
400 cd/m²
Color scale
100% sRGB
Characteristics
Anti-glare, ±80° horizontal viewing angle, ±80° vertical viewing angle, 35ms response speed, 0.179mm pixel pitch
Audio & Video
Graphics processor
NVIDIA RTX A500
Video memory
4 GB GDDR6 SDRAM
Camera
Yes - 1920 x 1080 (standard), 640 x 360 (infrared)
Resolution
2.07 Megapixel (standard), 0.23 Megapixel (infrared)
Type of image sensor
CMOS
Video resolution
1920x1080, 640x360
Frame rate
30 frames per second
Camera Features
Webcam protection, IR/RGB camera, Temporal Noise Reduction, 80 degrees, 86.6 degrees (IR camera)
Sound
Speaker, microphone with two positions
Standards followed
HD sound
Sound functions
Output: MaxxAudio 12.0, Realtek Waves
Input
Type
Keyboard, touchpad
Backlight, keyboard
Yes
Numeric keyboard
Yes
Communication
Wireless
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3
Wireless controller
Intel Wi-Fi 6E AX 211 - M.2 2230
Network interface
Gigabit Ethernet
Ethernet controller
Intel I219-LM
Characteristics
Dual stream (2x2), MU-MIMO
Battery
Technique
3-cell lithium ion
Capacity
54 Wh
AC adapter
Input
AC 100-240 V (50/60 Hz)
Output
130 Watts, 5 / 20 V
Connections & Expansion
Interface
HDMI
2 x USB4 (supports Thunderbolt 4, DisplayPort 1.4 Alt Mode) (Power Delivery)
USB 3.2 Gen 1 (PowerShare)
USB 3.2 Gen 1
LAN
Telephone/microphone combo jack
Memory card reader
Yes (microSD, microSDHC, microSDXC)
Software
Included software
Microsoft Office (30-day trial period, office license not included)
Various
Color
Gray
Integrated options
Accelerometer, ambient light sensor
Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip, smart card reader
Characteristics
ExpressChargeBoost
Theft/burglary protection
Safety lock slot (cable lock sold separately)
Type of security location
Noble Wedge safety location
Included accessories
USB-C power adapter
Standards followed
FIPS 140-2
Type of pricing
Build To Plan (BTP)
Weights and Measures
Dimensions (WxDxH)
35.78 cm x 23.33 cm x 2.28 cm
Weight
1,613 kg
